ER11
Collet multi-hole drill chuck machining center milling machine engraving machine chuck High speed engraving machine ER spring chuck.
The ER Collet Chuck is a versatile tool designed for use in various machining applications. It is suitable for machining centers, milling machines, engraving machines, and high-speed engraving machines. With its multi-hole drill chuck, it provides a reliable and efficient solution for holding and securing workpieces during machining processes.
The ER Collet Chuck is known for its high-speed performance and accuracy. It features an ER spring chuck mechanism that ensures a tight grip on the workpiece, preventing slippage and ensuring precise machining results. The collet chuck is designed to provide excellent concentricity, allowing for smooth and precise cutting operations.
With its durable construction and reliable performance, the ER Collet Chuck is a valuable tool for professionals in the machining industry. It offers easy installation and compatibility with various machines, making it a versatile and cost-effective solution for businesses. Whether you are working on a small-scale project or a large-scale production, the ER Collet Chuck is designed to deliver consistent and high-quality results.
| model number | Clamping range | height(mm) | external diameter(mm) | diameter of bore(mm) |
| ER8 | 1-5mm | 13.5 | 8.5 | 1 1.5 2 2.5 3 3.5 4 4.5 5 1/8 |
| ER11 | 1-7mm | 18 | 11.8 | 1 1.5 2 2.5 3 3.5 4 4.5 5 5.5 6 6.5 7 1/4 1/8 |
| ER16 | 1-10mm | 27.5 | 17 | 1 1.5 2 2.5 3 3.5 4 4.5 5 5.5 6 6.5 7 8 9 10 1/4 1/8 |
| ER20 | 1-13mm | 31.5 | 21 | 1 1.5 2 2.5 3 3.5 4 4.5 5 6 6.5 7 8 9 10 11 12 13 1/2 1/4 1/8 |
| ER25 | 1-16mm | 34.5 | 26 | 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 1/2 1/4 1/8 |
| ER32 | 3-20mm | 41 | 33 | 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 |
